MAX POWER EC Series
Built for extreme environments. With IP65 armor against sand/salt/moisture, it delivers 300-400KW at -40°C to 55°C. Powers highways, deserts & coasts. Features OCPP/RFID control, 4.3″ touchscreen, and global standards (GB/T/CCS/CHAdeMO). Unstoppable power.
OEM / ODM
Fast Charging
Long Service Life
IP65 protection
DC Charging Station
EC series
Engineered for Earth’s harshest frontiers, this IP65-sealed charging monolith (590×312×755mm, 55kg) delivers 30/40KW to EVs in -40°C Arctic blizzards or 55°C desert storms.
Specification of EC Series
| Product Parameters | |||
|---|---|---|---|
| Product Model | EC301K | EC401K | |
| Input Characteristics | Input Voltage | 260-485Vac,380V(rated) | |
| Frequency | 45-65HZ | ||
| Power factor | ≥0.98 | ||
| Input Current | 46A | 60A | |
| Ancillary sources | GB/T:12V 24V Optional CCS CHAdeMO:12V | ||
| Output Characteristics | Output power | 30KW | 40KW |
| Output voltage | 150-1000Vdc | ||
| Output power | 0-100A | 0-133A | |
| Charge Gun cable | 5M (about 4.5 meters out) | ||
| Working environment | Operating temperature | -40℃~ +55℃ (additional heaters can be added for cold areas) | |
| Operating humidity | 5~90RH%;(non-condensing) | ||
| Height above sea level | <2000M | ||
| Storage environment | Temperature | - 40 ~ 85℃; 25℃ | |
| Storage humidity | 5~95RH%;25RH%;(non-condensing) | ||
| Height above sea level | <2000M | ||
| IP Rating | IP65 | ||
| Human-computer interaction | 4.3” color touch screen | ||
| Size Weight | 590*312*755mm,55kg | ||
| Charging mode | OCPP / RFID / Plug and Play | ||
| Charging Standard | GB/T:GB/T 18487 、GB/T 20234、GB/T 27930; CCS:EN61851、EN62196、ISO15118、DIN70121 ; CHAdeM:CHAdeMO2.0 |
||

Sand/Salt/Moisture Immunity
- IP65 high protection charging pile, is your ideal choice to deal with moisture, corrosion, dust environment .
Long service life
- Extend service life, reduce maintenance cost, more stable performance


Applicable Scenarios
- Applicable scenarios: highway intersection, desert area, seaside and other harsh usage scenarios.
