Specification of OC15KW


Model

OC15750

INPUT

Voltage range

260-475Vac,380V(Rated)

Working frequency

45-65HZ

The power factor

≥0.99

Input current

30A

Auxiliary source

GB/T: 12V 24V OPT   CCS CHAdeMO: 12V

OUTPUT

Power

15KW

Voltage range

200-750Vdc

Output current

0-37.5A

Charging plug cable length

5M

The work environment

Temperature range

-20~50℃; 25℃ (type)

Humidity range

5~90RH%;  (non-condensation)

The altitude

2000M

Storage environment

Temperature range

- 40 ~ 85℃; 25℃ (type)

Humidity range

5~95RH%; 25RH%(type); (non-condensation)

The altitude

2000M

Dimensions and protection

Machine size(mm)

642*454*153mm

Packing size(mm)

Carton:790*610*380mm    Wooden box:790*610*470mm

Carton packing/weight

Carton weight 41kg, wooden case weight 59kg

The weight mentioned above is reference weight for standard configuration only. If the weight will increase due to the addition of accessories, the actual weight shall prevail

IP

IP54

The human-computer interaction

Charging mode

4.3 "color touch screen

Charger standard

Plug and play/OCPP/Credit card/password/reservation/offline billing /APP WIFI+ Bluetooth


GB/T: GB/T 18487, GB/T 20234, GB/T 27930

CCS: EN61851, EN62196, ISO15118, DIN70121

CHAdeMO: CHAdeMO


Dedicated to changing the way the world uses energy, Max Power creates advanced electric vehicle charging and energy management systems with a focus on all aspects of EV charging from home installations to business solutions.


The new wall-mounted OC15750, the 15kw DC Fast  EV Chargers can be customized in a variety of colours, including Black, White, Green,  Blue, or Grey, as well as options to have a longer 7 metre tethered charging cable than the standard 5 metre. All Max Power EV Chargers are suitable for home and public use and can be controlled through OCPP 1.6 which boasts a range of smart functions.
