Electric Car Charger with liquid cooling system
Liquid-Cooled DC Fast Charger Station
Wall-mounted | Floor-standed
CCS1
CCS2
CHAdeMO
GB/T
NACS
4.3-inch LED Screen
OCPP
Remote Control
RFID
IP54 Rating
OEM/ODM
Premium DC Fast Charger Station:
Liquid Cooling for Safety and Efficiency, Adaptable Deployment, and Multi-Mode Revenue Generation
Liquid Cooling for Efficient & Safe Operation
Advanced liquid cooling ensures effective heat dissipation, higher efficiency, and safer performance for this DC Fast Charger Station and broader electric vehicle charging system use.
Flexible Wall-Mounted or Floor-Standing Installation
Supports both mounting options, allowing the ev dc fast charger to fit various spaces and deployment needs with maximum flexibility.
Multiple Charging Modes for Higher Profitability
Offers diverse charging options to meet different EV requirements, enabling operators to boost revenue with a versatile dc fast charger solution.
Main Features of Our
DC EV Charger
As a leading global manufacturer of AC fast chargers, our solutions are ideally suited for both home and public use worldwide.
Charge for 1 Hour, Drive 180 km
The 22kW EV charger provides rapid DC fast charging, delivering up to 180 km of driving range in just one hour of charging. Ideal for commercial shared charging stations, this charger ensures minimal EV charging time, allowing users to get back on the road faster.
Advanced Liquid-Cooling System for Optimal Performance
Our liquid-cooled technology ensures efficient heat dissipation during charging, improving the overall performance and safety of the unit. The liquid cooling system keeps the charger at an ideal operating temperature, enhancing the lifespan of the charger and protecting against overheating in demanding DC fast charging stations.
OCPP Integration: Clear Operational Insights and Profitable Management
Supporting OCPP, this DC fast charger integrates with intelligent software for 24/7 monitoring, data collection, and operational management. The software tracks charger usage, reports activity frequency, and ensures efficient operation of the entire electric vehicle charging system, minimizing downtime and optimizing performance across your EV charging stations.
Universal Compatibility with All Major EV Connectors
With support for EV charging connector types including GB/T, CCS1, CCS2, and CHAdeMO, our DC fast charger is compatible with all major EV charging systems. This makes it a versatile solution for businesses and commercial locations offering fast charging for a wide range of electric vehicles.
Customizable Charging Modes for User Convenience
The DC charger for electric vehicle features customizable charging modes such as automatic charging, fixed power, fixed amount, and fixed time, giving users flexibility in how they charge. Whether at a DCFC charger station or home, this flexibility ensures optimized charging experiences based on individual needs.
Comprehensive Protection and Reliable Operation
The charger operates in extreme temperatures ranging from -25℃ to +50℃. It also features built-in safety protections, including overvoltage, undervoltage, overload, short circuit, and battery reverse protection, ensuring reliable and safe charging, even in harsh environments. This makes it perfect for use in commercial shared charging stations or high-demand settings.
Charge for 1 Hour, Drive 180 km
The 22kW EV charger provides rapid DC fast charging, delivering up to 180 km of driving range in just one hour of charging. Ideal for commercial shared charging stations, this charger ensures minimal EV charging time, allowing users to get back on the road faster.
Advanced Liquid-Cooling System for Optimal Performance
Our liquid-cooled technology ensures efficient heat dissipation during charging, improving the overall performance and safety of the unit. The liquid cooling system keeps the charger at an ideal operating temperature, enhancing the lifespan of the charger and protecting against overheating in demanding DC fast charging stations.
Customizable Charging Modes for User Convenience
The DC charger for electric vehicle features customizable charging modes such as automatic charging, fixed power, fixed amount, and fixed time, giving users flexibility in how they charge. Whether at a DCFC charger station or home, this flexibility ensures optimized charging experiences based on individual needs.
Comprehensive Protection and Reliable Operation
The charger operates in extreme temperatures ranging from -25℃ to +50℃. It also features built-in safety protections, including overvoltage, undervoltage, overload, short circuit, and battery reverse protection, ensuring reliable and safe charging, even in harsh environments. This makes it perfect for use in commercial shared charging stations or high-demand settings.
Universal Compatibility with All Major EV Connectors
With support for EV charging connector types including GB/T, CCS1, CCS2, and CHAdeMO, our DC fast charger is compatible with all major EV charging systems. This makes it a versatile solution for businesses and commercial locations offering fast charging for a wide range of electric vehicles.
OCPP Integration: Clear Operational Insights and Profitable Management
Supporting OCPP, this DC fast charger integrates with intelligent software for 24/7 monitoring, data collection, and operational management. The software tracks charger usage, reports activity frequency, and ensures efficient operation of the entire electric vehicle charging system, minimizing downtime and optimizing performance across your EV charging stations.
Charge for 1 Hour, Drive 180 km
The 22kW EV charger provides rapid DC fast charging, delivering up to 180 km of driving range in just one hour of charging. Ideal for commercial shared charging stations, this charger ensures minimal EV charging time, allowing users to get back on the road faster.
Advanced Liquid-Cooling System for Optimal Performance
Our liquid-cooled technology ensures efficient heat dissipation during charging, improving the overall performance and safety of the unit. The liquid cooling system keeps the charger at an ideal operating temperature, enhancing the lifespan of the charger and protecting against overheating in demanding DC fast charging stations.
Customizable Charging Modes for User Convenience
The DC charger for electric vehicle features customizable charging modes such as automatic charging, fixed power, fixed amount, and fixed time, giving users flexibility in how they charge. Whether at a DCFC charger station or home, this flexibility ensures optimized charging experiences based on individual needs.
Comprehensive Protection and Reliable Operation
The charger operates in extreme temperatures ranging from -25℃ to +50℃. It also features built-in safety protections, including overvoltage, undervoltage, overload, short circuit, and battery reverse protection, ensuring reliable and safe charging, even in harsh environments. This makes it perfect for use in commercial shared charging stations or high-demand settings.
Universal Compatibility with All Major EV Connectors
With support for EV charging connector types including GB/T, CCS1, CCS2, and CHAdeMO, our DC fast charger is compatible with all major EV charging systems. This makes it a versatile solution for businesses and commercial locations offering fast charging for a wide range of electric vehicles.
OCPP Integration: Clear Operational Insights and Profitable Management
Supporting OCPP, this DC fast charger integrates with intelligent software for 24/7 monitoring, data collection, and operational management. The software tracks charger usage, reports activity frequency, and ensures efficient operation of the entire electric vehicle charging system, minimizing downtime and optimizing performance across your EV charging stations.
| Product Parameters | |||
|---|---|---|---|
| Product Model | RC22500GO(GB/T) | RC22500EO(CCS2) | |
| Input Characteristics | Voltage range | AC Input Voltage： 360-440Vac | |
| Frequency | 50/60HZ | ||
| Power factor | ≥0.96 | ||
| Input Current | AC Input Current: 40 A | ||
| Input line length | 5 meters (standard) | ||
| Output Characteristics | Output power | 22KW | |
| Ancillary sources | GB/T 12V 24V optional, 12V for CCS2 | ||
| Voltage range | 150-750Vdc | ||
| Output Current | 0-72A | ||
| Charge Gun Cable | 5m (include charging gun cable length of 4.5m) | ||
| Module parameters | Heat dissipation method | liquid cooling | |
| Cooling medium | 50% water plus 50% ethylene glycol | ||
| Heat exchange | 1200W | ||
| Cooling Fan Power | 60W(MAX) 12VDC | ||
| Cooling water pump power | 66W 12VDC | ||
| static (in a signal) | 65dbm | ||
| IP Rating | IP65 | ||
| Human-computer interaction | 4.3-inch color touch screen | ||
| Charging mode | OCPP / RFID / Plug and Play | ||
| Operating temperature | -40℃~ +55℃ | ||
| Weight Size | Machine Size 642*454*153mm (without gun head,carrying handle, casters);Net Weight Approx. 43KG |
||
Please leave to us and we will be in touch within 24hours.
Frequently Asked Questions
How often are usage reports generated for your destination charger?
Our destination charger generates real-time usage reports, with automated summaries delivered on a daily, weekly, or monthly basis according to operator preferences. Guangzhou Max Power New Energy Technology Co., Ltd. enables users to customize reporting frequency through the charger’s management dashboard, ensuring that operators receive data at intervals aligned with their decision-making requirements. For instance, a hotel may choose daily reports to optimize management of peak guest charging periods, whereas a municipal council might prefer monthly reports to evaluate long-term infrastructure planning needs.
Can electric vehicle owners access their personal usage data from your EV destination charging stations?
Yes, EV owners can access their personal usage data from our EV destination chargers via Guangzhou Max Power’s mobile application or web portal. The available data includes detailed charging session information such as start time, duration, energy consumed, and a breakdown of associated charging costs. This functionality enables users to monitor their charging behavior, plan budgets for future travel, and support reimbursement claims for work-related charging activities—all while ensuring data privacy through secure user authentication.
Can the destination charger usage reporting assist in reducing operational costs for operators?
Certainly. Our destination charger usage reporting system enables significant reductions in operational costs by identifying inefficiencies in performance and maintenance. For instance, if reports indicate that a particular charger incurs high maintenance expenses due to frequent malfunctions, operators can proactively replace components or upgrade the unit to improve reliability. Furthermore, by analyzing energy consumption patterns, operators can leverage data to negotiate more favorable utility rates during off-peak charging periods, thereby reducing overall operating expenses. Clients of Guangzhou Max Power typically achieve a 15% to 20% reduction in operational costs within the first year of implementing our reporting solution.
Can a Commercial Charging Station Be Customized with a Business’s Branding?
Yes—Max Power offers customization options for commercial charging station models, including branded decals, color matching (to a business’s logo), and custom QR codes (linking to the business’s app or website). For example, a hotel business EV charging station can have the hotel’s logo printed on the SC Series chargers, reinforcing brand identity.
How Much Does It Cost to Operate a Business EV Charging Station?
Operating costs depend on usage and power rates, but Max Power’s business electric car charger minimizes expenses with 95% efficiency and >99% power factor. For a commercial charging station with 3×22KW chargers used 8 hours daily (average commercial rate of 0.15/kWh), monthly costs are ~234—far lower than the revenue or customer loyalty gains.
Is a Business EV Charging Station Compatible with All EV Models?
Max Power’s business electric car charger works with all major EV models (e.g., Tesla, Ford, Volkswagen) via universal connectors (CCS, CHAdeMO, Type 2). The 7-40KW power range adapts to each EV’s maximum charging capacity— a small car uses 7KW, while a fleet van uses 40KW. This compatibility means businesses don’t need to buy multiple charger types, simplifying inventory for wholesalers and reducing costs for clients.
Do Business Electric Car Charger Require Regular Maintenance?
Max Power’s business electric car charger requires minimal maintenance: monthly visual checks (for cable damage or debris) and annual software updates (done remotely via the cloud). The industrial-grade components and airflow isolation reduce wear, so most chargers need no major repairs for 5+ years. Wholesalers can offer maintenance packages (bundled with bulk orders) to provide clients with peace of mind, creating recurring revenue streams.
Can Max Power provide ODM and OEM services for custom charging stations?
Yes, absolutely. Max Power specializes in providing comprehensive ODM (Original Design Manufacturing) and OEM (Original Equipment Manufacturing) services to help businesses create customized charging solutions that meet their specific brand and market needs.
- ODM (Original Design Manufacturing) Service:With Max Power’s ODM service, you can design and develop a unique charging station from the ground up. Our expert team will work closely with you to bring your vision to life, ensuring the final product reflects your brand identity and technical requirements. We support you through the entire process—from initial concept and design, engineering, and prototyping to manufacturing and stringent quality control—delivering a charging station that is uniquely yours.
- OEM (Original Equipment Manufacturing) Service:If you already have a design or specific branding in mind, Max Power’s OEM service is the perfect solution. Simply provide us with your branding elements, such as logos, color schemes, and other visual assets, and we will incorporate them seamlessly into our high-quality charging station models. This allows you to offer a customized product quickly and efficiently, leveraging our manufacturing expertise without the need for extensive development.By partnering with Max Power for ODM or OEM services, you can launch a branded EV charging station that enhances your business identity, promotes customer loyalty, and demonstrates your commitment to innovation and sustainability. Custom charging stations are ideal for commercial properties, retail locations, fleet operations, and more, helping you stand out in the growing electric vehicle market.
