OC20KW

Contact Us
oc20kw 1
oc20kw 2
oc20kw 3
oc20kw 5
oc20kw 4
oc20kw 1

Specification of OC20KW


Model

OC20750

SC201K

INPUT

Voltage range

260-475Vac,380V(Rated)

Working frequency

45-65HZ

The power factor

≥0.99

Input current

32A

Auxiliary source

GB/T:12V 24V OPT   CCS CHAdeMO:12V

OUTPUT

Power

20KW

Voltage range

200-750Vdc

200-1000Vdc

Output current

0-50A

Charging plug cable length

5M

The work environment

Temperature range

-20~50℃;25℃ (type)

Humidity range

5~90RH%; (non-condensation)

The altitude

2000M

Storage environment

Temperature range

- 40 ~ 85℃; 25℃ (type)

Humidity range

5~95RH%;25RH%(type);(non-condensation)

The altitude

2000M

Dimensions and protection

Machine size(mm)

642*454*153mm

Packing size(mm)

Carton:790*610*380mm    Wooden box:790*610*470mm

Carton packing/weight

Carton weight 45kg, wooden case weight 64kg

The weight mentioned above is reference weight for standard configuration only. If the weight will increase due to the addition of accessories, the actual weight shall prevail

IP

IP54

OTHER

The human-computer interaction

4.3 "color touch screen

Charging mode

Plug and play/OCPP/Credit card/password/reservation/offline billing /APP WIFI+ Bluetooth

Charger standard

GB/T:GB/T 18487 、GB/T 20234、GB/T 27930

CCS:EN61851、EN62196、ISO15118、DIN70121

CHAdeMO:CHAdeMO
